yttria stabilized zirconia powder

yttria stabilized zirconia powder

Short Description:

Yttrium oxide stabilized zirconia (ZrO28Y2O3) is a zirconia crystal incorporated in zirconia crystals, which can form zirconia composed of fully stabilized cubic crystals and unstable monoclinic crystals.  It has good high temperature resistance, thermal shock resistance and insulation properties.

  • Product Name: ysz powder
  • Purity: 99.9%
  • Particle Size: 30-50nm, 100nm, 200nm, 1-2um, 5um
  • Sintered density: 5.8g/cm3
  • Color: white
  • Shape: powder
  • CAS: 1314-23-4
  • Brand Name: HR
  • Place of Origin: Sichuan,China
  • Product Detail

    Product Description

    Yttrium stabilized zirconia, also known as YSZ, is a new functional material with excellent properties.

    The crystal structure of YSZ is composed of zirconia and yttrium oxide, in which zirconia crystal structure is monoclinic crystal system and yttrium oxide crystal structure is cubic crystal system. This special crystal structure enables YSZ to have excellent properties such as high melting point, high hardness, high resistivity and low coefficient of thermal expansion.

    YSZ exhibits good thermal shock resistance at high temperatures, which is due to the high thermal stability of its crystal structure.

    YSZ has a wide range of applications in many fields, such as energy, environmental protection, aerospace, automotive, electronics, etc. In the energy sector, YSZ is widely used as an electrolyte material for solid oxide fuel cells (SOFC). In the field of environmental protection, YSZ can be used to remove harmful gases in the air and harmful substances in wastewater. In the aerospace and automotive sectors, YSZ can be used to manufacture high-performance ceramic materials and high-temperature resistant components.


    Yttria Stabilized Zirconia Powder Specificatioin
    Properit properties Type 4YSZ 5YSZ 8YSZ
    ZrO2(HfO2)% 95.7 94.7 91.7
    4.0Y2O3% 4.0+/-0.1 5.0+/-0.1 8.0+/-0.1
    SiO2% ≤ 0.005 0.005 0.005
    Fe2O3% ≤ 0.003 0.003 0.003
    CaO%≤ 0.002 0.002 0.002
    MgO≤ 0.003 0.003 0.003
    TiO2≤ 0.001 0.001 0.001
    Na2O≤ 0.001 0.001 0.001
    Cl≤ 0.1 0.1 0.1
    Lgnition%≤ 0.2 0.2 2
    Binder% 0 0 1
    Sintering Temperature 1500 1500 1500
    Sintered Density 6.05 6.05 6.05
    Three-point Flexural strength(Mpa) 1000 1000 1000
    Specific Surface Area(m²/g) 10+/-1 10+/-1 10+/-1
    Size 11-90um or customerized Size



    Quality control system


    Huarui has strict quality management system. We test our products first after we finish our production, and we test again before every delivery, even sample. And if you need, we would like to accept third party to test. Of course if you like, we could provide sample to you to test.

    Our product quality is guaranteed by Sichuan Metallurgical Institute and Guangzhou Institute of Metal Research. The long term cooperation with them can save a lot of testing time for customers.
